Nautilus®/Fornax® Transformer
For installing a Nautilus®/Fornax® casting machine without a 230 V outlet.
- Converts alternating current in the range 200 to 240 V, 50/60 Hz to 230 V, 50/60 Hz
Item #17800
Nautilus®/Fornax® Transformer
For installing a Nautilus®/Fornax® casting machine without a 230 V outlet.
Request a QuoteMost Popular Downloads
Nautilus®/Fornax® Transformer Specifications
For installing a Nautilus®/Fornax® casting machine without a 230 V outlet.
| Technical data | |
|---|---|
| Height | 145 mm |
| Width | 127 mm |
| Depth | 245 mm |
| Weight | 5.5 kg |
| Input voltage | 200/210/220/230/240 VAC |
| Input current (max.) | 19.4 A |
| Output voltage | 230 VAC |
| Output current (max.) | 16 A |
| Power output | 3680 VA (40% Duty Cycle) |
| Protection class | I |
| Protection type | IP 23 |
| Ambient temperature (max.) | 40° C |
| Availability | REF |
|---|---|
| Nautilus®/Fornax® Transformer | 17800 |
Nautilus®/Fornax® Transformer Resources
| Title | Type | |
|---|---|---|
| Casting Machines Brochure | Brochure | Download |
